Product Certificate
Product Parameter
| Art. number |
P08PM-C02SN |
| Power source |
COB(main) 1x SMD(torch) |
| Rated power (W) |
6W(main) 1W(torch) |
| Luminous flux(±10%) |
100-450lm(main) 100lm(torch) |
| Color temperature |
5700K |
| Color rendering index |
95(main) 65(main) |
| Bean angle |
84°(main) 42°(torch) |
| Battery |
18650 3.7V 2600mAh |
| Operating time(approx.) |
2.5-8H(main), 10H(torch) |
| Charging time(approx.) |
2.5H |
| Charging voltage DC (V) |
5V |
| Charging current (A) |
Max. 2A |
| Charging port |
TYPE-C |
| Charging input voltage (V) |
100 ~ 240V AC 50/60Hz |
| Charger included |
No |
| Charger type |
EU/GB |
| Switch function |
Torch-main(100%)-off, long press switch: main light 10%-100% |
| Protection index |
IP65 |
| Impact resistance index |
IK08 |
| Service life |
25000 h |
| Operating temperature |
-10°C ~ 40°C |
|
Store temperature: |
-10°C ~ 50°C |
Poduct Details
| Art. number |
P08PM-C02SN |
| Product type |
|
| Body casing |
ABS+TRP+PC |
| Length (mm) |
55 |
| Width (mm) |
44 |
| Height (mm) |
205 |
| N.W. per lamp (g) |
300g |
| Accessory |
Lamp, manual,1m USB -C cable |
| Packaging |
color box |
| Carton quantity |
25 in one |
Product Application/Key Feature
Conditions
Sample leading time: 7 days
Mass production leading time: 45-60 days
MOQ: 1000 pieces
Delivery: by sea/air
Warranty: 1 year upon goods arrive destination port
Accesorry
N/A
FAQ
Q: How to tell if the battery is fully charged?
A: The 4 LEDs indicators under the main light window all light on.
Q: Does the charging base is included in standard packaging?
A: Yes, also 1 meter USB-C cable.
Q: Where does the work light be used often?
A： In workshop, for car detailing and color match for paint job.
